2025 Trailmaster Cheetah200 [E]X

Trailer

Call for Price

Request Info

View Inventory

Specs and Features

Specifications
Highlighted Features

Engine Information

EPA certificated

Engine type

4-stroke, single cylinder, air cooled

Displacement

169cc

Max HP

11hp/7500rpm

Max torque

8.2 lb ft/6000rpm

Bore x stroke

2.4x2.28 inches

Climbing ability

12 degrees

Ignition

C.D.I

Starting system

Electric

Battery

12V 10Ah

Carburetor brand

Deli (Vacuum film)

Engine oil

SAE 15W-40

General Information

Clutch

Automatic CTV with reverse

Driveline / Driving wheel

Chain / Dual wheel drive

Suspension F / R

Double A-arm / swing-arm

Brakes, F / R

Both hydraulic brakes, Disc

Tires, F / R

22x7-10 / 22x10-10

Wheel

Alumilum

Fuel capacity

2.64 gal

Weight, G.W. / N.W.

650 / 521 lbs

Max load

500 lbs

Dimension Information

Wheelbase

71 inches

OA L x W x H

92.1x55x58.3 inches

Height to seat

18.5 inches

Min ground clearance

5.9 inches

Pedal to seat back distance

36” to 42”
