2025 KTM 300 XC

Orange

MSRP: $11,499

Request Info

View Inventory

Back to Showroom

Specs and Features

ENGINE

Transmission

6-speed

Starter

Electric starter

Stroke

72 mm

Bore

72 mm

Clutch

Wet, DDS multi-disc clutch, Brembo hydraulics

Displacement

293.2 cm³

EMS

Vitesco Technologies EMS

Design

1-cylinder, 2-stroke engine

Fuel-mixture generation

Keihin EFI, throttle body 39 mm

CHASSIS

Weight (without fuel)

101.8 kg

Tank capacity (approx.)

9 l

Wheelbase

1493 mm

Front brake disc diameter

260 mm

Rear brake disc diameter

220 mm

Front brake

Disc brake

Rear brake

Disc brake

Chain

520 X-Ring

Frame design

Central double-cradle-type 25CrMo4 steel

Front suspension

WP XACT cartridge Ø 48 mm

Ground clearance

354 mm

Handlebar

Neken, aluminium Ø 28/22 mm

Rear suspension

WP XACT Monoshock with linkage

Seat height

954 mm

Silencer

Aluminium

Steering head angle

63.9 °

Rear subframe design

Aluminum-reinforced polyamide

Suspension travel (front)

300 mm

Suspension travel (rear)

300 mm

Wheels

Spoked wheels with aluminium rims

2025 KTM 300 XC

The 2025 KTM 300 XC casts a pretty imposing shadow. Not only does it feature a legendary 2-stroke depth charger at its core, but it now also boasts refined suspension settings, a reworked frame, and one of the leading power-to-weight ratios in the open class. When hare scrambles and offroad racing were conceived, the KTM 300 XC was the poster child.

Easy Suspension Adjustment

The 2025 KTM XC and XC-F range took their already awesome suspension package and turned it up to 11. The WP XACT Closed Cartridge spring forks and WP XACT rear shock has been updated, with reworked settings and alterations to improve weight distribution and increase overall response. As always, the suspension boasts an easy tool-free setup at both ends, ensuring you chase down the podium in total control. On the rear, a hand-adjustable dual compression control allows riders to adjust high- and low-speed settings in a matter of seconds. The forks on the front end are also easily adjusted thanks to hand-adjustable clickers on the bottom of the fork shoe and top cap.

More Usable Power

This 300 cc 2-stroke powerhouse brings a new choice of weapon to the Open category and provides more choice for racers looking for maximum power at the least possible weight. Along with low maintenance costs and an overall engine weight of just 52.6 lb, the 2025 KTM 300 XC provides pure performance. Coupled together with advanced technical innovations, e-start, electronic fuel injection, and an electronic exhaust control, this is the new cross country kingpin.

Absolute Control

No matter how gnarly the trail is, you'll stay in control thanks to a rider-focussed frame design that has not only been engineered for longitudinal rigidity, but also positions rotating mass as close as possible to the center of gravity. Thick frame walls also improve reliability, flex characteristics and offer unmatched rider feel. The shock mounting also provides the perfect amount of anti-squat for better traction out of corners, while the footpeg mounting position reduces the risk of hooking up on roots or rocks. Additionally, forged brackets on the lower frame rails allow for easy installation of the skid plate.

Mass Centralization

The 2025 KTM XC and XC-F range receive some major frame updates directly from Factory Racing efforts. For starters, the frame area around the rear shock mount has been updated, and more streamlined. The front area of the frame is also updated. with a different wall thickness compared to the previous model year, with renewed engine mounts. This adds up to a 300g weight saving, and improved flex for better cornering behavior.
