2025 Can-Am Defender DPS HD9

Compass Green

Wildland Camo

Stealth Black

Fiery Red

MSRP: $14,399

Request Info

View Inventory

Back to Showroom

Specs and Features

ENGINE

Type

HD9: 65 hp / 59 lb-ft, Rotax® 976 cc, V-twin, liquid cooled

Fuel Delivery System

Intelligent Throttle Control (iTC™) with Electronic Fuel Injection (EFI)

Transmission

HD9: PRO-TORQ CVT with Quick Response System (QRS), high airflow ventilation and Electronic Drive Belt Protection

Drive Train

HD9: Selectable Turf Mode / 2WD / 4WD with Visco-Lok† auto-locking front differential

Driving Assistance

CVT Engine Braking ECO™ / ECO™ Off / Work modes Speed Limiter

Power Steering

Dynamic Power Steering (DPS)

Suspension

Front Suspension

HD9: Double A-arm / 10 in. (25.4 cm) suspension travel

Front Shocks

Twin tube gas charged shocks

Rear Suspension

HD9: TTA with external sway bar / 10 in. (25.4 cm) suspension travel

Rear Shocks

Twin tube gas charged shocks

TIRES/WHEELS

Front Tires

HD9: XPS Trail Force 27 x 9/11 x 14 in.

Rear Tires

HD9: XPS Trail Force 27 x 9/11 x 14 in.

Wheels

14 in. cast-aluminum

Brakes

Front

Dual 220 mm disc brakes with hydraulic twin-piston calipers

Rear

Dual 220 mm disc brakes with hydraulic single-piston calipers

Technology

N/A

Dimensions / Capacities

Length

121 in (307.1 cm)

Width

62 in (157.5 cm) 64 in (162.5 cm)

Height

76 in (193 cm) 78 in (198.1 cm)

L x W x H

HD9: 121 x 62 x 76 in. (307.1 x 157.5 x 193 cm)

Wheel Base

83 in. (211.5 cm)

Ground Clearance

HD9: 11 in. (28 cm)

Chassis Cage

Profiled cage ROPS approved

Estimated Dry Weight*

HD9: 1,541 lb (699 kg)

Cargo Box Dimensions

38 x 54.5 x 12 in. (96.5 x 138.4 x 30.5 cm)

Cargo Box Capacity

1,000 lb (454 kg) / California only: 600 lb (272.2 kg)

Tailgate Load Capacity

250 lb (113.4 kg)

Storage Capacity

Total: 10.4 gal (39.5 L)

Towing Capacity

2,500 lb (1,134 kg)

Payload Capacity

1,500 lb (680 kg)

Fuel Capacity

10.6 gal (40 L)

Person Capacity

Features

Gauge

4.5 in. wide digital display

Battery

12-V (18 amp/h)

Magneto

650-W

Instrumentation

DC outlet (10-A)

Lighting

Front lighting output 140-W, LED tail lights

Winch

N/A

Seat

VERSA-PRO bench seat with passenger seats flipping up Underside hooks

Steering Wheel

Adjustable tilt steering

Protection

Integrated front steel bumper,, HMWPE central skid plate

Hitch Type

2 in. hitch receiver

Gauge

Type of gauge

4.5 in. wide digital display

Warranty

Factory

1-year BRP Limited warranty

Extended Service Terms

B.E.S.T. term available up to 30 months

Defender DPS

TAKE THE REIGNS. Dynamic Power Steering (DPS) makes for a workhorse that drives well at every turn. Fill the adaptable storage, engage 4WD, & drive the best without stretching your wallet.

Leading Engine

The HD10 engine is class-leading with 69 lb-ft of torque! The break-in period, early maintenance and frequent valve adjustments are all things of the past. The powerpack design delivers an improved riding experience, with less noise & vibration.

Speed limiter

Sometimes you just have to rein in all the power of this workhorse for seeding, crop spraying or moving cargo. With the new speed limiter available on all Defenders, you're the one in control. Get ready for peak work efficiency.

Speed limiter

Industry-leading cargo box of 4.5 x 6 ft long - with 1,000 lb (454 kg) cargo box capacity, an easy flat-bed conversion and a hydraulic power tilt bed - there’s no limit. This multi-function cargo box can be customize any way you want.

Audio Roof

Here's the new waterproof sound system available in option. Six 7.7’’ speakers with Bluetooth compatibility, multi-colored LEDs, an RMC amp and a genuine Rockford Fosgate audio receiver to crank up your playlists when you’re out there in the fields herding or baling to the beat of your own drum. Sounds good? You bet!

HVAC

Features an automatic & a variable compressor mode that improves efficiency. Dial in heating, ventilation or air conditioning to keep the cabin temperature exactly how you like and lock in that temperature with the painted full doors.

Under Bed Storage

Exclusive full-width under bed storage for cargo, gear, tools, and more. That's in addition to removable side panels, a dump mechanism, and 100% more loading space than the Defender. Enjoy gimmick-free practicality that's ready to haul with strength and space to spare.
